Morton Top Glazed with Laminate Office Partitions
Made with 2 panels, the Morton top glazed partitions have a white laminate panel with a glazed window section located at the top of the screen. With the clear acrylic at the top, some natural light can filter into the space, whilst being mostly covered.
As for the base, the white gloss laminate is easy to clean and also accepts dry wipe pens. Use the panel to divide in addition to being a white board in training and meeting spaces.
Dispatched within 10 working days
- Includes stabilizing feet and 2 way link strip
- Clear acrylic as standard
- Frosted acrylic on request
- Black, white and silver powder coated frame
- Bottom panel – White gloss laminate
- Made in the UK, by Rap Office Screens
Key Features
As a multi panel screen, the vision top design can thrive in environments from offices to medical spaces. The versatile materials are easy to clean so fair well in medical spaces where hygiene is the main agenda.
Need the white board on the go? Switch the trip and wheelchair friendly feet for the castor wheels. On castors, the vision office partition is highly portable and can be moved from room to room.
- Made to order
- Linking partition design
- HPL (high pressure laminate)
- Whiteboard feature
- For privacy, request the frosted acrylic
Product specifications for the Morton Vision Office Screen range.
Frame Measurements
Frame thickness - 28mm
Frame width - (side bars) - 50mm / (Top & bottom bar) - 22mm
Acoustic screen thickness (Core, foam & fabric) - 42mm
Foot slots in the frame are 290.5mm in from each end (Varied on screens 800mm W & smaller)
Materials
Frame - Powder coated aluminium
Stability feet - Steel
*stability feet are trip and wheelchair friendly
Feet raise the screen by 25mm and protrude 230mm from either side of the screen
Acrylic - 3mm clear and frosted acrylic
White gloss laminate - HPL (high pressure laminate)
Internal - 18mm solid core
Foam - 12mm fire retardant acoustic foam
Linking strips - Flexible PVC
Fire Safety Elements
Foam
12mm Combustion Modified Foam BS 5852-2: using ignition Source 5 Crib
Chipboard
Surface spread of Flames Class 2 tested to BS479-7
MDF
Surface spread of Flames Class 2 tested to BS479-7
Plastic Components
Manufactured using non-flammable, self-extinguishing plastic.
Aluminium
Extrusions has a melting of 660°C and is not considered to be a fire hazard.
Steel
Components are not considered to be a fire hazard.
Acrylic
Tested to BS 476 Part 7 with a Class 3 classification
Laminate
Tested to standard UNE EN 13501-1:07+A1:2010
Fabric
Woven Fabric - Morton Standard
Woven Collection has been tested to BS 5867-2: 2008 & BS 7176 2007
Universe Fabric - Morton+
Universe Collection has been tested to BS 5867-2: 2008 Type B
Are the Morton Visions still acoustic?
The Morton Vision version with the acoustic base, has some level of acoustic property. But due to addition of acrylic, the partition isn’t as acoustically effective as the Morton Acoustic Office Screen.
The Morton Vision with the laminate bases offer no acoustic properties due to the hard material of the acrylic and laminate.
Can I add a logo to the acrylic section?
Yes, on the full, half and top vision it’s possible to add a logo, or custom print of choice on to the acrylic section of the divider.
Can I use different Morton Screens together?
It’s possible to link and use any of the Morton Vision and Standard Acoustic Screens together. All screens are supplied with a flexible linking strip so your configuration can be created from arrival.
Is it possible to return screening?
As we make each screen to order based on the selected size, fabric and frame colour, we’re unable to accept returns. View our full terms and conditions.
